Spray Drying of Chinese Herbal Medicine and Plant Extracts

Kampo medicines (Chinese Herbal Medicines) and plant extracts with unique active ingredients are widely used as medicines, health foods, and food additives. Kampo medicines are medicines made with herbal medicines based on the theory of traditional Chinese medicine. For example, the well-known Kakkonto is a medicine containing seven herbal medicines: kudzu root (pueraria root), ephedra (mahuang), jujube (taiso), cinnamon bark, peony root (shakuyaku), licorice root (kanzo), and ginger (shokyo). In addition to herbal medicines, a wide variety of plant extracts, including green tea catechins, ginkgo, pine needles, moringa, maca, turmeric, coptis, gentian, angelica and salacia are used as medicines or health foods. Many of these products are distributed as powders, granules, or tablets. Powders have a smaller mass and volume than liquids, which helps reduce transportation costs. In addition, because they are dried products, they can be stored for a long period of time.

The manufacturing process for herbal and plant extract powders in general is as follows:

Weighing and Blending → Extraction and Filtration → Concentration and Sterilization → Drying and Granulation → Filling and Packaging

Weighing and Blending
Since plant ingredients are naturally derived, there is a certain amount of variability in the balance of ingredients. Therefore, maintaining quality by weighing and mixing ingredients under strict quality control is required.

Extraction and Filtration
Extraction is proccessed using warm water, hot water, steam, etc. Extraction methods include immersion, drip, and microwave, and extraction conditions such as temperature and time are set according to the components to be extracted. The extracted extract is filtered using a centrifuge, etc., before moving on to the concentration process.

Concentration and Sterilization
The extract is concentrated in a low-temperature concentration process using an evaporator, etc. The extract is sterilized either at the same time as the concentration or in the next process, and then moves on to the drying process.

Drying and Granulation
The concentrated extract is spray-dried and powdered. The spray-dried powder may be used as is or, depending on the variety, may be further granulated or tableted using a tablet pressing machine.

Filling and Packaging
The product powders and tablets are filled and packaged before being boxed and shipped.

Spray drying of Chinese herbal medicine and plant extracts is generally performed at a low drying temperature for gentle drying. Under low temperature operating conditions, the liquid dries slowly, which tends to result in a higher bulk density. On the other hand, under high temperature conditions, the droplets dry in a short time, which accelerates the formation of particle shells. This can cause particles to expand, burst, or become hollow due to internal evaporation. The moisture content is higher under low temperature conditions and lower under high temperature conditions. Liquid atomization methods can be selected from rotary atomizers, two-fluid nozzles, pressure nozzles, and ultrasonic nozzles. When selecting an atomization method, not only the droplet size but also the effects of physical contact and friction must be taken into consideration.

Since many of the raw materials are highly hygroscopic and multi-component, it is necessary to design a spray dryer that can adequately prevent product adhesion during the process. Specifically, dehumidified air is introduced into all or part of the process gas. In addition, air sweeper or dehumidifying air line may be installed in the drying chamber. It is also important to appropriately set the temperature and humidity of the powder recovery line. For example, the powder quality may be kept constant at the time of product collection by optimizing the temperature of dehumidified air as well as the powder transportation distance through the powder conveying line. In addition to adjusting the raw material with additives, oxidation can also be prevented from a process perspective by using inert gas as the process gas for the spray dryer.

For raw materials, the concentration, presence or absence of additives, and the amount of additives added are key indicators. Increasing the concentration of the raw material reduces the amount of water that evaporates per unit time, thereby improving production efficiency. However, the concentration of the raw material affects the particle size and density of the product, so an appropriate value must be determined. By adjusting the type and amount of additives, we control the residual rate of flavor components, the solubility of the powder, etc. Trehalose and cyclodextrin, a cyclic oligosaccharide, may also be added to mask or stabilize specific components and improve flavor.

Volatile components usually have low boiling points and evaporate during spray drying, but adding maltodextrin, cyclodextrin, oligosaccharides, etc. makes it possible to retain the components. For example, cyclodextrin can encapsulate the molecules of volatile components within its hydrophobic cavity, reducing the loss of components during spray drying. This is effective in slowing the release of flavor components in products. Similarly, by adding an appropriate concentration of coating additives and spray drying at lower temperature, it is possible to produce powders containing alcohol, such as powdered alcohol, that retain a high residual alcohol content. When high-quality powdered alcohol is redissolved in water, it is possible to restore not only the alcohol but also the flavor of the liquid alcohol.

In general, spray drying involves the evaporation of the solvent from the droplet surface, and the movement of moisture from the droplet to the surface, causing the entire droplet to shrink. At the same time as the moisture moves, the solid content within the droplet moves outward, forming a particle structure. As a result, the particles tend to have a high density outer shell and a low density or hollow interior. Furthermore, in suspensions, if there are multiple particle components contained in the liquid and each particle has a different particle size and density, segregation may occur inside the granules due to particle movement during drying. It is important to understand the physical properties of the raw materials, particle size, density, internal structure, etc. of the dried particles, and then to control the operating conditions appropriately.

The main parameters for quality control of powder products are the residual rate of flavor components, color, particle size distribution, bulk density, and moisture content. In addition, flowability, wettability, solubility, color, and particle surface properties related to taste may also be included. Regarding particle size, larger particles have good flowability and are easy to fill into containers, so they have a high bulk density. The opposite is true for small particles, which have a low bulk density. If the bulk density value is unstable, the stability during product filling will decrease. Large particles have a small specific surface area, which means that moisture does not escape easily during drying, and the moisture content tends to be high. Small particles have a large specific surface area, which means that moisture escapes easily, resulting in a low moisture content. On the other hand, highly hygroscopic powders may re-absorb moisture contained in the exhaust air, resulting in small particles with a high moisture content and large particles with a low moisture content.

Our spray dryers have a proven track record in the spray drying process of Chinese herbal medicine and plant extracts. Based on our accumulated experience and expertise, we design optimal spray drying processes and set operating conditions that meet the required quality. By optimizing the various conditions of the spray drying process, we control powder quality that exceeds customers’ expectations. In addition, our freeze granulator is a brand new powder manufacturing process that may overcome the weaknesses of spray-dried products and freeze-dried pulverized products. Regarding freeze granulation technology, we have introduced more information in “About Freeze Granulation“, “Advantages of Freeze Granulation in Foods, Beverages and Pharmaceuticals (Comparison with Grinded Freeze-Dried Products)” and “High Viable Bacteria Rate – Spray Drying and Freeze Granulation“.

We not only provide powder processing trials for spray drying, spray cooling, and freeze granulation, but also services that include pre- and post-powder processing, such as wet pulverizing, mixing, molding, sintering and freeze-drying. We operate a total of three locations: two Powder Technical Centers in Japan and ASEAN Powder Technical Center in Thailand. Our brand new Powder Technical Center 2 (PTC2), which was newly established in 2023, has one of the largest collections of analytical measurement equipment in Japan. We provide one-stop support for powder processing and analytical measurements (Powder Trials & Analytical Measurements/Contract Powder Processing).
